The LR45 low level lift has a lifting capacity of up to 4500kg.
It is designed to raise all four the wheels from the ground up to maximum height of 800 mm, with a mechanical locking system to prevent the vehicle from lowering prematurely.
It has a total width of 2100mm and is ideal to pick up wider vehicles like the Toyota Quantum’s.
Technical information
Lifting capacity: 4500 kg
Max capacity – front axle: 2273 kg
Max capacity – rear axle: 2273 kg
Lifting height (no blocks): 578 mm
Lifting height (with blocks): 800 mm
Overall pad length: 1346 mm
Overall length: 2094 mm
Overall pad width: 610 mm
Overall width: 2159 mm
Lowered height: 102 mm
Lifting time: 1 35 seconds
Motor: 110/208-230 VAC / 50/60 Hz. 1Ph
